Universal Height Master 5-1010mm 515-523 Mitutoyo

Universal Height Master 5-1010mm 515-523 Mitutoyo
  • Rating:
    0 reviews
  • Manufacturer:
    Mitutoyo
  • Model:
    515-523
  • Available:
    In stock
  • Block pitch accuracy:
    Range ≤ 310 mm: ±1.5 μm 310 < range ≤ 610 mm: ±2.5 μm 610 < range ≤ 1010 mm: ±3.5 μm
  • Block step:
    10 mm straight
  • Delivered:
    In a wooden case with certificate of inspection
  • Feed error:
    ±1.5 µm
  • Graduation:
    0.001
  • Inch-Metric:
    Metric
  • Mass:
    63.5
  • Micrometer adjustment:
    20 mm
  • Micrometer feed:
    0.5 mm
  • Parallelism of blocks:
    Range ≤ 610 mm: 1,5 μm 610 < range ≤ 1010 mm: 2 μm
  • Range:
    5 - 1,010
  • Retrace error:
    1.5 µm
15,586.00€
In stock

Description

This height master offers you the following benefits:
  • You can use it to calibrate and set height gauges and other measuring instruments.
  • Models with the staggered arrangement of blocks have two measuring faces on the same level, one facing up and the other down.
  • It is supplied in a fitted wooden case.
