Point Micrometer with Hardened Tip 75-100mm, 15° Tip 112-156 Mitutoyo

Point Micrometer with Hardened Tip 75-100mm, 15° Tip 112-156 Mitutoyo
  • Rating:
    0 reviews
  • Manufacturer:
    Mitutoyo
  • Model:
    112-156
  • Available:
    In stock
  • Delivered:
    Including box, spanner, setting standard
  • Digital/Analog:
    Analog
  • Graduation:
    0,01 mm
  • Inch-Metric:
    Metric
  • Mass:
    500
  • Max. Permissible Error J MPE:
    ±4 µm
  • Measuring face:
    Carbide pointed or hardened steel spindle and anvil, measuring point radius 0.3 mm
  • Measuring force:
    3 - 8
  • Measuring spindle:
    With spindle lock, ø6,35 mm, spindle pitch 0,5 mm
  • Range:
    75 - 100
  • Scale:
    Thimble and sleeve satin chrome finish, ø18 mm
  • Tip:
    15°
378.00€
In stock

Description

A Mitutoyo non-digital micrometer provided with pointed spindle and anvil to enable measurement within curved, slotted features, such as drilling-bit web thicknesses. A ratchet stop guarantees repeatable measurement.
