Micrometer Head, Differential Screw 0-1mm, 0,001mm, Flat 110-105-10 Mitutoyo

Micrometer Head, Differential Screw 0-1mm, 0,001mm, Flat 110-105-10 Mitutoyo
  • Rating:
    0 reviews
  • Manufacturer:
    Mitutoyo
  • Model:
    110-105-10
  • Available:
    In stock
  • Delivered:
    In a paper box with spanner 200154
  • Digital/Analog:
    Analog
  • Fixture thickness for clamp nut:
    9.5
  • Graduation:
    0.001 mm
  • Inch-Metric:
    Metric
  • Mass:
    150
  • Max. Permissible Error J MPE:
    ±3 µm / ±1.5 µm
  • Maximum Permissible Error J MPE (Narrow):
    ±1.5 µm
  • Measuring face:
    Carbide tipped (>90 HRA)
  • Range:
    0 - 1
  • Spindle end:
    Flat
  • Stem:
    w/ clamp nut
  • Stem Ø:
    12
265.00€
In stock

Description

This is a differential screw translator (extra-fine feed) type of micrometer head.
It offers you the following benefits:
  • Micrometer head with ultra-fine rate of travel.
  • With its non-rotating spindle it is particularly suited to fine adjustments.
  • The differential travel mechanism with double spindle enables ultra-sensitive travel
