Dial Snap Gauge without Indicator 9-10" 201-160 Mitutoyo

Dial Snap Gauge without Indicator 9-10" 201-160 Mitutoyo

Rating:

0 reviews
Manufacturer:
Mitutoyo
Model:
201-160
Available:
In stock11
Anvil retracting stroke:
2 mm
Delivered:
Including thermally insulating grip, workpiece stop
Digital/Analog:
Analog
Flatness:
1 µm
Inch-Metric:
Inch
Mass:
1540
Measuring face:
Carbide-tipped, micro-lap finish (13.5x12 mm)
Measuring force:
12 - 18
Parallelism:
0,0002"
Range:
9 - 10
Remarks:
For indicator with 9.52 mm stem
Repeatability:
2 µm

Price: 733.00€

In stock

Quantity:

Description

A Mitutoyo dial snap gauge designed for quick GO/NG judgement of diameters of cylinders and shafts. Anvils are chamfered for easy workpiece insertion. The dial indicator is optional, enabling the user to choose from the wide range available to best suit the application.
