Dial Indicator, Lug Back, AGD/ANSI 4", 0,001", Shockp., Coax. Rev. Counter 3428S-19 Mitutoyo

Dial Indicator, Lug Back, AGD/ANSI 4", 0,001", Shockp., Coax. Rev. Counter 3428S-19 Mitutoyo
  • Rating:
    0 reviews
  • Manufacturer:
    Mitutoyo
  • Model:
    3428S-19
  • Available:
    In stock
  • Coaxial revolution counter:
    Yes
  • Contact point:
    Carbide tipped, thread: 4-48UNF
  • Continuous dial:
    Yes
  • Delivered:
    With certificate of inspection, bezel clamp, limit hands
  • Dial reading:
    ±0-100
  • Digital/Analog:
    Analog
  • Graduation:
    0,001"
  • H MPE (Hysteresis):
    0,00033"
  • Inch-Metric:
    Inch
  • Mass:
    366
  • Measuring force:
    0,4-3,2
  • MPE > 10-20 revolutions:
    ±0,003"
  • MPE > 2 1/2-10 revolutions:
    ±0,002"
  • MPE > 20 revolutions:
    ±0,005"
  • MPE first 2 1/2 revolutions:
    ±0,001"
  • MPE first one revolution:
    ±0,001"
  • R MPE (Repeatability):
    ±0,0002"
  • Range:
    4
  • Range per rev.:
    0,1"
  • Shockproof:
    Yes
  • Stem:
    9.52 mm / 0.375"
  • Type:
    ANSI/AGD Standard
192.00€
In stock

Description

A Mitutoyo shockproof, multi-revolution dial indicator suited to general measurement applications in a vertical orientation. The jewelled movement provides lowest friction and stiction for smooth and precise operation and the bi-directional scale aids measurement in both directions.
