3-Point Internal Micrometer Holtest 8-10mm, 0,001mm 368-162 Mitutoyo

3-Point Internal Micrometer Holtest 8-10mm, 0,001mm 368-162 Mitutoyo

Rating:

0 reviews
Manufacturer:
Mitutoyo
Model:
368-162
Available:
In stock11
Delivered:
Including box, spanner, hex wrench, certificate of inspection, without setting ring
Digital/Analog:
Analog
Graduation:
0,001 mm
Inch-Metric:
Metric
Mass:
60
Max. Permissible Error J MPE:
±2 µm
Measuring face:
Titanium coated tungsten carbide taper: tungsten carbide
Measuring method:
3-point
Measuring spindle:
Spindle pitch 0,5 mm
Range:
8 - 10
Scale:
Thimble and sleeve satin chrome finish, Up to 12 mm : Ø 17 mm Over 12 mm : Ø 23 mm

Price: 397.00€

In stock

Quantity:

Description

A non-digital 3-point Mitutoyo bore micrometer with titanium-coated measuring pins. The 3-point design enables stable measurement through automatic centering. The maximum measuring depth can be increased by 100mm using an optional extension rod if required. Ratchet stop guarantees repeatable measurement. Steel setting rings (optional) are available for accurate setting prior to measurement.
