3-Point Internal Micrometer Holtest 25-30mm, 0,005mm 368-167 Mitutoyo

3-Point Internal Micrometer Holtest 25-30mm, 0,005mm 368-167 Mitutoyo
  • Rating:
    0 reviews
  • Manufacturer:
    Mitutoyo
  • Model:
    368-167
  • Available:
    In stock
  • Delivered:
    Including box, spanner, hex wrench, certificate of inspection, without setting ring
  • Digital/Analog:
    Analog
  • Graduation:
    0,005 mm
  • Inch-Metric:
    Metric
  • Mass:
    280
  • Max. Permissible Error J MPE:
    ±3 µm
  • Measuring face:
    Titanium coated hardened steel taper: tungsten carbide
  • Measuring method:
    3-point
  • Measuring spindle:
    Spindle pitch 0,5 mm
  • Range:
    25 - 30
  • Scale:
    Thimble and sleeve satin chrome finish, Up to 12 mm : Ø 17 mm Over 12 mm : Ø 23 mm
517.00€
In stock

Description

A non-digital 3-point Mitutoyo bore micrometer with titanium-coated measuring pins. The 3-point design enables stable measurement through automatic centering. The maximum measuring depth can be increased by 150mm using an optional extension rod if required. Ratchet stop guarantees repeatable measurement. Steel setting rings (optional) are available for accurate setting prior to measurement.

Reviews (0)

Write a review
